Expanded Metal Mesh Machine

JIAKE Machinery has been counted as one of the top advanced high-speed expanded metal mesh machine manufacturers, suppliers, and exporters in the universal market since 1999.

The machine produces expanded metal, Expanded metal is a type of sheet metal that has been cut and stretched to form a regular pattern (often diamond-shaped holes) of mesh-like material.

According to the thickness of the raw materials that customers need to punch, the required punching dies are also different. Therefore, we have 6.3T, 16T, 25T, 40T, 100T, 160T, and 260T seven types of expanded metal mesh machines, and through the industry With more than 30 years of experience and knowledge, we can provide our customers with the best solutions.

 Types of metal:

Aluminum coil/panel, galvanized coil/panel, stainless steel coil/panel, iron coil/panel, mild steel, iron steel, carbon steel

 Machine Features:

1. Expanded metal mesh line adopts PLC program and text screen, easy to operate.
2. Raw material can be galvanized steel plate, iron plate, aluminum plate, stainless steel plate, etc.
3. The machine can produce different types of the expanded metal mesh by different cutters.
4. Expanded mesh machine adopts step motor to control steel plate feeding, more accurate.
5. The finished mesh is in rolls or flattened panels.
6. Pneumatic brake device.
7. The machine is widely used in construction, hardware, fence, window and door, protection, etc.

 Specification of Expanded Metal Mesh Machine:

Model Punch speed (r/m) Max. LWD
(mm)
Material
Thickness
(mm)
Max.
Width
(mm)
Feeding distance
(mm)
Motor
(KW)
Weight
(T)
6.3T 300 20 0.2-1.5 650 0-5 4/1440 1.2
16T 260 30 0.2-1.5 1000 0-5 5.5/1440 2.8
25T/1.2 260 30 0.2-1.5 1250 0-5 5.5/1440 3.3
25T/1.5 260 30 0.2-1.2 1500 0-5 5.5/1440 3.9
40T 110 80 0.2-2.5 1500 0-10 11/1440 6
63T 75 120 0.5-3 2000 0-5 15/1440 11
100T 60 180 0.5-5 2000 0-10 18.5/1470 13
56 180 0.5-5 2500 0-10 22/1470 14
160T 55 200 0.5-6 2000 0-10 30/1470 16
45 200 0.5-5 2500 0-10 30/1470 18
45 200 0.5-4 3200 0-10 30/1470 20
260T 32 200 1-8 2000 0-10 55/1470 26
32 200 1-8 2500 0-10 55/1470 28
TG10 500 12 0.1-1.0 650 0-6 7.5/1000 1.5

 Machine Video:

 Layout of Expanded Mesh Production Process:

expanded_metal_mesh_line_layout

How is the expanded mesh made?

1. Sheets or coils of metal are fed into the metal mesh machine. A little metal can create a lot of mesh, adding value and saving resources and money.

2. As the metal sheet is fed through the expanded metal machine, it is cut and stretched simultaneously using a pressured slitting and stretching process.

3. For the expanded mesh, the flattening machine not only flattens the lap joint of the steel mesh, but also makes the surface of the stencil smooth and beautiful, and at the same time, can eliminate the internal force generated during the weaving process, thereby improving the stencil steely.

4. There are two types of mesh recoiler, one is to roll the expanded metal mesh into a roll; the other is to cut the expanded mesh into a certain length of sheet mesh by the PLC system.

 Typical application of expanded metal mesh:

Expand metal application is very broad: Fencing for the garden, back yard, residential and industrial facilities, Floor treads, stairs, transport vehicles, construction machinery, cranes, mining, bakery, and food industry, Production in the electrical industry protective mesh, batteries, grounding plates, which include heating protection, masks, electric water heaters, etc.

expanded_metal_mesh_application

 FAQ:

Q: What’s the machine price?
A: Please tell me the material type (galvanized plate or stainless-steel plate), plate thickness, mesh opening size, and mesh width you want.
Q: Can you make the machine according to my voltage?
A: Yes, usually the popular voltages are 3 phase, 380V/220V/415V/440V, 50Hz or 60Hz, etc.
Q: Can I make different mesh sizes on one machine?
A: The mesh hole size can be adjusted by changing cutters. The mesh width can be adjusted.
Q: How many workers are needed to operate the line?
A: 1 worker.
Q: What are your payment terms?
A: 30% T/T in advance, 70% T/T before shipment, or L/C, or cash, etc. It is negotiable.
